i + 1 loop with conditions

remeng · Oct 26, 2020

Hi All;

I am sure that this is an easy one, but I forgot how to finish this code off.

The goal is for a user to enter a starting number (i) between 1 to 120. If the number is within the range of 1 to 120, it runs the IF statement. Once the IF statement is run, I'd like to perform a Next i operation. The code would end once i is greater than 120. The problem is where to put the For and Next statements.

Here is my code:

Code:

Sub multi_panel_2()

Dim i As Single

i = InputBox("What panel number would you like to start with?", "Starting Panel Number")


    If i >= 1 And i <= 120 Then

         confirm = MsgBox("Are you ready to run file " & "panel" & i & ".tap" & " ?", vbOKCancel)

            If confirm = 1 Then

                MsgBox ("run " & i & ".tap") ' placeholder for file call

                ' loadrun("c:\CNC\panel" & i & ".tap")
                ' code "M00"


            Else: End If 'place holder for  code "M30" End If



    Else: MsgBox ("You entered Panel " & i & ".  " & "Panel number is outside the range of 1 to 120.")

        End If


End Sub

Andrzejek · Oct 26, 2020

Just a guess here since your requirements are not very clear to me...

Code:

Sub multi_panel_2()

Dim i As Single[blue]
Dim x As Integer[/blue]

i = InputBox("What panel number would you like to start with?", "Starting Panel Number")

If i >= 1 And i <= 120 Then[blue]
    For x = i To 120[/blue]
        confirm = MsgBox("Are you ready to run file " & "panel" & i & ".tap" & " ?", vbOKCancel)

        If confirm = 1 Then
            MsgBox ("run " & i & ".tap") ' placeholder for file call
                ' loadrun("c:\CNC\panel" & i & ".tap")
                ' code "M00"
            Else: End If 'place holder for  code "M30" End If        [blue]
    Next x[/blue]
Else
    MsgBox ("You entered Panel " & i & ".  " & "Panel number is outside the range of 1 to 120.")
End If

End Sub

BTW - what if your user enters "XYZ" as the answer to your InputBox [ponder]

---- Andy

There is a great need for a sarcasm font.

SkipVought · Oct 26, 2020

I think that the variable i needs to change, therefore...

Code:

Sub multi_panel_2()

Dim i As Integer
Dim x As Integer

x = InputBox("What panel number would you like to start with?", "Starting Panel Number")

If x >= 1 And x <= 120 Then
    For i = x To 120
        confirm = MsgBox("Are you ready to run file " & "panel" & i & ".tap" & " ?", vbOKCancel)

        If confirm = 1 Then
            MsgBox ("run " & i & ".tap") ' placeholder for file call
                ' loadrun("c:\CNC\panel" & i & ".tap")
                ' code "M00"
            Else: End If 'place holder for  code "M30" End If
    Next x
Else
    MsgBox ("You entered Panel " & x & ".  " & "Panel number is outside the range of 1 to 120.")
End If

End Sub

Skip,
_{Just traded in my OLD subtlety...

for a NUance!}
"The most incomprehensible thing about the universe is that it is comprehensible" A. Einstein

remeng · Oct 27, 2020

Hi Skip,

As always, thank you for the assistance. When I run your code, I get an Invalid Next Control variable reference. I understand where you are going with it, but don't know how to fix the error.

Thanks,

Mike

combo · Oct 27, 2020

Check the counter name, it should be the same as after Next.

Wouldn't be easier to create a simple userform with input textbox, dynamically filled multiselect listbox (can have rather ugly built-in checkboxes and depending on the developer either not selected or preselected all items), two buttons: first, 'update list' with value check and filling list, and second, 'go'? You could avoid up to 120 replies to "Are you ready to run file ...".

combo

Andrzejek · Oct 27, 2020

In Skip's example:

Code:

...
Next x   [green]'<- change x to i[/green]
...

or in my example:

Code:

...
Dim i As Single    [green]'<- change Single to Integer[/green]
Dim x As Integer
...

---- Andy

There is a great need for a sarcasm font.

remeng · Oct 27, 2020

Hi combo,

The vb is going to be used in Mach3 as a macro for a CNC router. Mach3 doesn't support forms. I'm not 100% sure that this will work either but if it works in office,it'll be a good start.

Mike

SkipVought · Oct 27, 2020

You'll want to take the message box related code out of the loop.

Skip,
_{Just traded in my OLD subtlety...

for a NUance!}
"The most incomprehensible thing about the universe is that it is comprehensible" A. Einstein

combo · Oct 27, 2020

I'm not sure if this Cypress basic manual refers to the language you use, but if so:
- MsgBox type and buttons are coded in single [Type] parameter (pp. 100-102),
- vbOKCancel constant does not exist,
- you can build dialogs, there is no visual designer, but [tt]Begin Dialog ... End Dialog[/tt] structure (pp. 60-61).

combo

Andrzejek · Oct 28, 2020

Since this is Microsoft VBA for Applications forum, I would assume Mike is using something like Excel VBA
If so, his MsgBox could be written:

Code:

Select Case MsgBox("Are you ready to run file panel" & i & ".tap ?", [blue]vbOKCancel[/blue] Or vbQuestion, "Ready?")
    Case vbOK

    Case vbCancel

End Select

but - since this is a "Are you ready" question, I would expect Yes / No answers:

Code:

Select Case MsgBox("Are you ready to run file panel" & i & ".tap ?", [blue]vbYesNo[/blue] Or vbQuestion, "Ready?")
    Case [blue]vbYes[/blue]

    Case [blue]vbNo[/blue]

End Select

---- Andy

There is a great need for a sarcasm font.

combo · Oct 28, 2020

Andy, if you look at the manual I linked, you can see that it is 99% VB(A). Mach3 site states thet the language is the same as Cypress. It is not VBA however in this post: "The vb is going to be used in Mach3 as a macro for a CNC router. Mach3 doesn't support forms." Some structures are different and I suspect that the full code was not tested in real environment.
Much simpler if the code could run from a file created in VBA supporting application and use automation.

combo

Andrzejek · Oct 28, 2020

Ooops! My fault. I missed the Mach3 part... [blush]

---- Andy

There is a great need for a sarcasm font.

remeng · Oct 28, 2020

Hi Folks,

Thanks for the assistance. Mach3 does support message boxes and all the other properties in the MS Office code. I did check.

My current code is working for the most part. There is one problem though. The NEXT loop will keep going as it should, but I need to do something a little different since during testing I ran across a situation that needs to be corrected.

Before each new file, I need to confirm that the operator wants to run it. I think the issue with the code is just an order of operation situation.

Steps:

1) Start macro
2) User enters the panel number into the message box prompt
3) A confirmation box is used to validate the starting point input value
4) The file is run (place holder continue)
5) the user's input number + 1
6) Verify that the user wants to run the next panel number (user's input + some value between 1 and 120)
7) The file is run
8) repeat till all files are run

What do I need to amend?

current code:

Code:

Sub multi_panel_3()

Dim i As Integer
Dim x As Integer

x = InputBox("What panel number would you like to start with?", "Starting Panel Number")

If x >= 1 And x <= 120 Then

        confirm = MsgBox("Are you ready to run file " & "panel" & x & ".tap" & " ?", vbOKCancel)

        If confirm = 1 Then



            continue = MsgBox("run " & x & ".tap", vbOKCancel)  ' placeholder for file call

            If continue = 1 Then

                ' loadrun("c:\CNC\panel" & i & ".tap")
                ' code "M00"
            For i = x To 120

            Next i

            End If

        Else: End If 'place holder for  code "M30" End If

Else
    MsgBox ("You entered Panel " & x & ".  " & "Panel number is outside the range of 1 to 120.")
End If

End Sub

Thanks for the assistance!

Mike

SkipVought · Oct 28, 2020

Code:

Sub multi_panel_3()

Dim i As Integer
Dim x As Integer

x = InputBox("What panel number would you like to start with?", "Starting Panel Number")

If x >= 1 And x <= 120 Then

        confirm = MsgBox("Are you ready to run file " & "panel" & x & ".tap" & " ?", vbOKCancel)

        If confirm = 1 Then



            continue = MsgBox("run " & x & ".tap", vbOKCancel)  ' placeholder for file call

            If continue = 1 Then


            For i = x To 120
                [b]'Answer = Msgbox here to run the cnc
                'If Answer = No Then Exit For[/b]
                ' loadrun("c:\CNC\panel" & i & ".tap")
                ' code "M00"
            Next i

            End If

        Else: End If 'place holder for  code "M30" End If

Else
    MsgBox ("You entered Panel " & x & ".  " & "Panel number is outside the range of 1 to 120.")
End If

End Sub

Skip,
_{Just traded in my OLD subtlety...

for a NUance!}
"The most incomprehensible thing about the universe is that it is comprehensible" A. Einstein

Andrzejek · Oct 28, 2020

This makes a little more sense (to me, at least...) VBA approach, I hope it works the same in Mach3

Code:

Sub multi_panel_3()[green]
'1) Start macro[/green]
Dim i As Integer
Dim x As Integer
[green]
'2) User enters the panel number into the message box prompt[/green]
x = InputBox("What panel number would you like to start with?", "Starting Panel Number")

If x < 1 or x > 120 Then
    MsgBox ("You entered Panel " & x & ".  Panel number is outside the range of 1 to 120.")
    Exit Sub
End If
[green]
'3) A confirmation box is used to validate the starting point input value[/green]
If vbOK = MsgBox("Are you ready to run file panel" & x & ".tap" ?", vbOKCancel) Then
    For i = x To 120
        If vbOK = MsgBox("run " & x & ".tap ?", vbOKCancel) Then [green]
            ' loadrun("c:\CNC\panel" & i & ".tap")
            ' code "M00"[/green]
        End If
    Next i
End If

End Sub

'Starting point' question in MsgBox will be asked twice.
Do you really need to ask first time?

---- Andy

There is a great need for a sarcasm font.

strongm · Oct 28, 2020

>I would assume Mike is using something like Excel VBA

Nah, if they are trying to script Mach 3, then they are using the Mach 3 scripting language, which is Cypress Enable, which is a VBA-alike - one that doers not appear to have any built-in predefined constants ... Combo has already linked to a relevant manual

Andrzejek · Oct 28, 2020

>[Mach 3] doers not appear to have any built-in predefined constants
But it looks like [tt]vbOKCancel[/tt] works OK for Mike... [ponder]

---- Andy

There is a great need for a sarcasm font.

combo · Oct 29, 2020

We see the InputBox code result, no MsgBox ...

remeng said:
Before each new file, I need to confirm that the operator wants to run it. I think the issue with the code is just an order of operation situation.

For MsgBox, if in Mach3 [tt]vbOKCancel=0[/tt], only OK button is displayed and 1 returned, 1=1, so we always enter the [tt]For...Next[/tt] loop. According to the manual, the code should be:
[tt]confirm = MsgBox("Are you ready to run file " & "panel" & x & ".tap" & " ?", 1+32, "Confirm run")[/tt]

combo

remeng · Nov 2, 2020

Hi All;

I am still having the issue. Andrzejek code doesn't keep the NEXT loop going.

Again, I think it is an order of operation in my code.

Combo,

I don't understand what your last message meant. It might be just the formatting of the post. Could you please clarify?

Thanks,

Mike

combo · Nov 2, 2020

Assumed you have Cypress VB script (you have not confirmed this). I am basing on the manual I linked to above.

If your script does not support VB/VBA named constans, in [tt]confirm = MsgBox("Are you ready to run file " & "panel" & x & ".tap" & " ?", vbOKCancel)[/tt] you have [tt]vbOKCancel=0[/tt], unless earlier you declared it as =1. If you pass o, the manual states 'Display OK button only.' Is it your case? If so, as MsgBox function returns the value of button clicked, you get [tt]confirm=1[/tt] (i.e. OK button selected, no other option). In next line you have [tt]If confirm = 1 Then[/tt], that is always True. The same refers to next lines and 'continue' testing.

You need to assign 1 to MsgBox Type argument if you plan to have OK and Cancel buttons. 32 is for question icon, not necessary, but in line with the message purpose.

combo
